Logistics transfer from stamping workshop / stamping line to stamping warehouse

Project Consulting

    Environmental conditions:

    Ambient temperature: -5-45 ℃
    Relative humidity: 50% ~ 98%
    Voltage: AC 220V / 380V × 50Hz
    Control voltage: DC 48V
    Compressed air: 0.4 ~ 0.6MPa



    Basic road conditions:

    Pavement requirements: ground difference ± 5mm / ㎡
    Pavement slope: within 2%



    Drive unit:

    Steering wheel drive



    System structure:

    1. Execution equipment
    2. Network Media
    3. Host system



    Communication equipment:

    Wireless WIFI



    Power supply system:

    48V / 100Ah lithium battery / online intelligent charging



    Transport process:

    AGV hauled Dolly online while waiting for the material frame to be filled manually. After manual release, it was automatically transferred to the warehouse discharge point. The forklift driver returned to the line after replacing the empty material frame.



    Customer benefits:

    AGV replaces the traditional human forklifts and human tractors for transportation, reducing the number of logistics and distribution personnel in the factory by 20 people; saving millions of labor costs; reducing the number of forklifts and tractors by nearly ten; and ultimately achieving unmanned and efficient transfer area Ensure the safety of personnel in the factory.



    Solution advantages:

    1. Design highlights: two-way with traverse function
    2. Reducing personnel dependence: no need for a forklift license, reducing the risk of operators, eliminating training and reducing dependence on personnel experience
    3. Avoid mistakes: avoid manually picking up the wrong goods, eliminating the line loss caused by wrong execution
