Huajun U series
All-around / Underlying Type12+ Product Parameter Information
12+ Product parameters
- Payload capacity : 0-6000KG
- Navigation mode : Magnetic tape/fluorescence line /laser
- Moving direction : Omnidirectional
- Drive mode : Differential drive/steering wheel/mecanum wheel
- Moving speed : 5-60
- Control mode : PLC/SCM
- Positioning accuracy : ±10mm
- Turning radius : 1200mm
- Gradeability : 3° (70% load)
- Working mode : Underlying type
- Designed dimension : 2960L*1450W*460H
- Charging mode : Online/offline
- Safety protection : Obstacle detection+safety bumper+safety lamp
- 产品特点
-
- Commodity name: Huajun U series
- Payload capacity: 0-6000KG
- Navigation mode: Magnetic tape/fluorescence line /laser
- Moving direction: Omnidirectional
- Drive mode: Differential drive/steering wheel/mecanum wheel
- Moving speed: 5-60
- Control mode: PLC/SCM
- Positioning accuracy: ±10mm
- Turning radius: 1200mm
- Gradeability: 3° (70% load)
- Working mode: Underlying type
- Designed dimension: 2960L*1450W*460H
- Charging mode: Online/offline
- Safety protection: Obstacle detection+safety bumper+safety lamp
All-around / Underlying Type
