Project Background

The first domestic bank to introduce the AGV + smart vault project, the industry benchmark.

The banking industry belongs to a special industry, with special technological processes, no lessons from the past, and strict laws and regulations. The transportation of cash, vouchers, precious metals, etc. in the treasury has always been carried by hand, which is labor intensive, requires multiple people to supervise each other, and the security inspection procedures are cumbersome. In this project, CSG Huaxiao deeply researched the user's pain points, and the AGV + intelligent vault system developed in cooperation with the bank realized the automation of management links such as storage, inventory, sorting and unpacking, saving labor and improving work efficiency.

The project has been appreciated by the bank leaders, and as a lighthouse project, other banks have come to visit and learn from it, which is very popular.

Environmental conditions:

Ambient temperature: -5-45 ℃
Relative humidity: 50% ～ 98%
Voltage: AC220V / 380V × 50Hz
Control voltage: DC 24V
Compressed air: 5.0 Kg / cm²

Basic road conditions:

Pavement requirements: the level of the flat surface on the basis of ± 5mm / m², the total length does not exceed 12mm
Pavement slope: within 2°
Undulation degree: vertical deviation is ± 5mm / m², the total length does not exceed 10mm

Transport process:

AGV is decomposed according to the inbound and outbound instructions of the upper-level system and the tasks of the picking system, and is responsible for the transfer between various areas in the vault

Project outcome:

The project design uses warehousing AGV to complete the automatic transfer of luggage in the vault; for the first time, a PTL seeding wall is used in the bank vault to ensure that the distribution tasks during the peak distribution period are accurate; the WMS system tailored for the vault is coordinated with the luggage RFID scanning Management, APP fingerprint verification, completely realize paperless office, effectively reduce manual identification and mis-operation of orders, and improve the overall work efficiency of the vault.

Features:

Navigation advantages: QR code navigation, suitable for storage environment
Safety protection: obstacle sensor
Design highlights: small size, fast speed, high storage efficiency

System structure:

Treasury system → PTL system → WMS system → AGV management system

Drive unit:

Differential drive

Communication equipment:

Wi-Fi communication

Power supply system;

48V / 30Ah lithium battery / online intelligent charging

Environmental conditions:	Basic road conditions:	Transport process:
Ambient temperature: -5-45 ℃ Relative humidity: 50% ～ 98% Voltage: AC220V / 380V × 50Hz Control voltage: DC 24V Compressed air: 5.0 Kg / cm²	Pavement requirements: the level of the flat surface on the basis of ± 5mm / m², the total length does not exceed 12mm Pavement slope: within 2° Undulation degree: vertical deviation is ± 5mm / m², the total length does not exceed 10mm	AGV is decomposed according to the inbound and outbound instructions of the upper-level system and the tasks of the picking system, and is responsible for the transfer between various areas in the vault

Project outcome:	Features:
The project design uses warehousing AGV to complete the automatic transfer of luggage in the vault; for the first time, a PTL seeding wall is used in the bank vault to ensure that the distribution tasks during the peak distribution period are accurate; the WMS system tailored for the vault is coordinated with the luggage RFID scanning Management, APP fingerprint verification, completely realize paperless office, effectively reduce manual identification and mis-operation of orders, and improve the overall work efficiency of the vault.	Navigation advantages: QR code navigation, suitable for storage environment Safety protection: obstacle sensor Design highlights: small size, fast speed, high storage efficiency

System structure:	Drive unit:
Treasury system → PTL system → WMS system → AGV management system	Differential drive

Communication equipment:	Power supply system;
Wi-Fi communication	48V / 30Ah lithium battery / online intelligent charging
