Huajun U series Huajun U series

Huajun U series

All-around / Underlying Type12+ Product Parameter Information

12+ Product parameters
  • Payload capacity : 0-6000KG
  • Navigation mode : Magnetic tape/fluorescence line /laser
  • Moving direction : Omnidirectional
  • Drive mode : Differential drive/steering wheel/mecanum wheel
  • Moving speed : 5-60
  • Control mode : PLC/SCM
  • Positioning accuracy : ±10mm
  • Turning radius : 1200mm
  • Gradeability : 3° (70% load)
  • Working mode : Underlying type
  • Designed dimension : 2960L*1450W*460H
  • Charging mode : Online/offline
  • Safety protection : Obstacle detection+safety bumper+safety lamp

Huajun U series

零售价

市场价


All-around / Underlying Type

重量

Quantity
-
+

库存

隐藏域元素占位

  • 产品特点
    • Commodity name: Huajun U series
    • Payload capacity: 0-6000KG
    • Navigation mode: Magnetic tape/fluorescence line /laser
    • Moving direction: Omnidirectional
    • Drive mode: Differential drive/steering wheel/mecanum wheel
    • Moving speed: 5-60
    • Control mode: PLC/SCM
    • Positioning accuracy: ±10mm
    • Turning radius: 1200mm
    • Gradeability: 3° (70% load)
    • Working mode: Underlying type
    • Designed dimension: 2960L*1450W*460H
    • Charging mode: Online/offline
    • Safety protection: Obstacle detection+safety bumper+safety lamp

    All-around / Underlying Type
